⚡ QUICK ANSWER On a stock Toyota FJ Cruiser (2007–2014) with factory suspension and factory wheels, the biggest tire that fits with zero rubbing is 275/70R17 (32.2″). A true 33 like 285/70R17 (32.7″) fits with mud flap delete and Spidertrax 1.25″ wheel spacers. Real 35s need a 3″+ lift, body mount chop, aftermarket UCAs, and usually a regear. |
The FJ Cruiser was in production for seven model years (2007–2014) but its cult following has grown bigger every year since Toyota killed it. The combination of the 1GR-FE 4.0 V6, body-on-frame construction, a real transfer case with a rear locker on TRD Off-Road models, and a retro silhouette built to honor the FJ40 makes the FJ Cruiser one of the most sought-after Toyota off-roaders on the used market. Prices are climbing, the aftermarket is still deep, and owners are pushing builds harder than ever.
This guide covers every FJ Cruiser configuration: base, Upgrade Package #1 and #2, the Trail Teams special editions (2008 Voodoo Blue, 2010 Sandstorm, 2011 Army Green, 2012 Radiant Red, 2013 Trail Teams Cement, 2014 Heritage Blue and Ultimate Edition), and the TRD Special Edition. We'll cover stock, 2″ leveled, 3″ lifted, and the 35″+ builds where things get serious.
Battle Born Clothing is a Nevada print shop, not a tire shop. But Rob wheels an FZJ80 Land Cruiser and the FJ Cruiser community is family to the broader Land Cruiser tribe. If you're here for fitment data and walk out with a vintage FJ40 tee, that's a good day. Jump to the Land Cruiser collection or vintage Toyota hats if that's why you're here.
Stock Tire Sizes by Trim: What Toyota Shipped From the Factory
The FJ Cruiser came with two factory wheel diameters, and offset/backspacing that's worth knowing before you buy new rubber. Here's the breakdown:
| TRIM / PACKAGE | WHEEL | OFFSET | STOCK TIRE | DIAMETER |
| Base (steel 16″) | 16x7.5 steel | +15mm | P265/75R16 | 31.6″ |
| Upgrade Pkg #1 / #2 (17″) | 17x7.5 alloy | +15mm to +20mm | P265/70R17 | 31.6″ |
| Trail Teams (TT) Editions | 17x7.5 alloy (TT design) | +15mm | P265/70R17 | 31.6″ |
| TRD Special Edition (2008) | 17x7.5 TRD | +15mm | P265/70R17 | 31.6″ |
| Trail Teams Ultimate (2014) | 17x7.5 Baja-style | +15mm | 265/70R17 BFG KM2 | 31.6″ |
Takeaway: Every single FJ Cruiser shipped with a 31.6″ tire regardless of trim. The backspacing is about 4.84″, offset +15mm to +20mm, which is tucked further in than almost any other body-on-frame Toyota. That's the reason wider tires hit the upper control arms so quickly on a stock FJ.
The UCA Problem: Why FJ Cruiser Fitment Is Different
Here's what makes the FJ different from a Tacoma or a 5th gen 4Runner: the factory wheel backspacing puts the tire very close to the upper control arm. On a Tacoma, you can run a 285mm-wide tire at stock offset with only liner trimming. On an FJ, you hit the UCA at full lock before you hit the fender.
The community standard fix is 1.25″ Spidertrax hub-centric wheel spacers. They push the tire outward to clear the UCA without requiring new wheels. Install them once with extended studs and proper torque, and you're good for life. Spidertrax has become the FJ community default for a reason: they work and they don't fail.
The other consideration is the body mount behind the front tire. Any tire wider than about 11.5″ (think 33x12.50 or 305/70R17) will rub the body mount at full lock when the suspension compresses. The fix is the infamous Body Mount Chop (BMC): cut the outer portion of the mount, weld in a fill piece, and you reclaim about an inch of clearance.
Biggest Tires on Stock Suspension: No Lift, No Chop
On 17″ Wheels (most trims)
| TIRE SIZE | DIAMETER | FITMENT |
| 265/70R17 (stock) | 31.6″ | Factory size. Zero rubbing. |
| 275/70R17 | 32.2″ | MAX no-mod size. Zero rubbing on stock wheels. |
| 285/70R17 (true 33) | 32.7″ | Usually rubs UCA without spacers. Works with 1.25″ Spidertrax + mud flap delete. |
| 33x10.50R17 (skinny 33) | 33.0″ x 10.5″ | Clears UCA easier due to narrow width. Some builds fit with no spacers. |
| 33x12.50R17 | 33.0″ x 12.5″ | Spacers required. Body mount rubbing at full lock off-camber. |
On 16″ Wheels (base steel)
| TIRE SIZE | DIAMETER | FITMENT |
| 265/75R16 (stock base) | 31.6″ | Factory size. |
| 275/70R16 | 31.2″ | Zero rubbing, slightly wider look. |
| 285/75R16 (true 33) | 32.8″ | Needs 1.25″ spacers + mud flap delete. |
| 255/85R16 (skinny 33) | 33.1″ x 10.0″ | Tall, narrow. Clears UCA better than wider 33s. |
Real-world verified: A 2013 FJ running 285/70R17 BFG All-Terrain on stock wheels with 1.25″ Spidertrax spacers fits with no rubbing in normal driving. A stock-suspension FJ running 33x12.50R17 on 8″ aftermarket wheels at +16 offset fits without rubbing in some cases, though the mud flaps usually come off.
Biggest Tires with a 2″ Front Level
The easiest FJ Cruiser upgrade is a front leveling kit. OME 883 or 884 coils, Bilstein 5100s at setting 2, Toytec Boss adjustable coilovers, Icon stage 1, or a simple top plate spacer all raise the nose 1.5″–2.5″ and open up more tire options. Important note from the community: a lift does not create tire clearance at full compression. It raises static ride height only.
| TIRE | DIAMETER | MODS NEEDED |
| 285/70R17 | 32.7″ | 1.25″ Spidertrax spacers + mud flap delete. |
| 33x12.50R17 | 33.0″ x 12.5″ | Spacers + liner trim. BMC usually needed for off-camber. |
| 305/70R17 | 33.8″ x 12.0″ | 2″ spacers + subframe trim (verified by builds with 2″ lift). |
33-Inch Tires on a 3″ Lift: The FJ Sweet Spot
The classic FJ Cruiser build: 3″ lift with true 33s (285/70R17 or 285/75R16). You get real approach and departure angle gains, the stance looks right, and you clear most of the problem areas without the full chaos of a 35″ build. Common lift choices: OME 2.5″ kit with BP-51 shocks, Toytec Boss 3″, Icon stage 3, Total Chaos long travel.
Required Mods for 33s on a 3″ Lift
- 1.25″ Spidertrax wheel spacers OR lower-offset aftermarket wheels (0mm to +5mm offset)
- Mud flap delete, front and rear
- Front fender liner push-back and repin
- Light trim on front fender lip
- Body Mount Chop (BMC) strongly recommended for any serious off-road use
- Aftermarket upper control arms (Total Chaos, Camburg, Icon) to correct caster and add a few mm of UCA clearance
- Rear bump stop extensions to prevent rear flex rubbing
- Regear to 4.56 optional (stock 3.727 is workable on 33s)
35-Inch Tires on an FJ Cruiser: The Serious Build
Running 35s on an FJ is a commitment. The 1GR-FE has enough torque to pull them but the chassis was not designed for that much rubber. Here's what a proper 35″ FJ build requires:
What You Need for 35s
- 3.5″–4″ suspension lift (OME Heavy Duty, Toytec Boss, Icon stage 4, or long-travel)
- Aggressive Body Mount Chop (cut it back as far as structurally sound)
- Aftermarket upper control arms (Total Chaos and Icon are FJ community favorites)
- Firewall-side plastic and fender flare trimming
- Rear bump stop extensions
- Body lift (1″ or 2″) often combined with suspension lift
- 1.25″–1.75″ wheel spacers OR wheels with −12mm to −25mm offset
- Regear strongly recommended: 4.56 for daily drivers, 4.88 for weekend warriors, 5.29 for dedicated trail rigs with 8″ rear diff
- Possible rear differential drop bracket for pinion angle
Budget for a proper 35″ FJ build: $10,000–$18,000 depending on parts choice and whether you pay a shop. If you're going past 35s, you're looking at 37s which require a body mount relocation (not just chop) and significant wheel well cutting and welding. Some builders have gone to solid axle swaps to handle 37s and bigger.
The Three Variables That Actually Decide Fitment
1. Tire Diameter & Width
Published sizes vary from actual measurements by up to half an inch between brands. A BFG KM3 in 285/70R17 measures differently than a Nitto Trail Grappler in the same size. Check the manufacturer spec sheet for actual section width and overall diameter before ordering. On an FJ, width matters more than height because of the UCA.
2. Wheel Offset & Spacers
Stock FJ offset is +15mm to +20mm with 4.84″ backspacing. For tires wider than 275mm, you're either adding Spidertrax 1.25″ spacers or buying aftermarket wheels with 0mm to +5mm offset (which effectively moves the tire outward the same distance). Both approaches work.
3. Suspension Lift (What It Does And Doesn't Do)
Lift raises your static ride height so a bigger tire looks right. It does not change the geometry at full compression. When you flex the suspension hard off-road, the tire ends up in roughly the same position relative to the wheel well as an unlifted truck. Real off-road clearance comes from trimming, offset, and UCAs, not from lift height alone.
“33s are probably the most common tire upgrade among FJC owners since you really don't have to do much to make them work. In fact, you could install these on a bone stock rig with very minimal rubbing, if any, depending on the specific tire, wheel, and front-end alignment.”
— RESZ Fabrication, FJ Cruiser Tire Fitment Guide
FJ Cruiser vs. Land Cruiser Heritage: A Design Note
Toyota designed the FJ Cruiser as a direct visual tribute to the FJ40 Land Cruiser, which is why the aftermarket overlap between FJ40 restoration builds and modern FJ Cruiser builds runs so deep. Both share the round headlights, the vertical grille bar, the white roof, and the boxy stance. Owners who wheel FJ Cruisers often end up with FJ40 or FZJ80 rigs in the garage too.
If you're curious about the engine heritage, the 1GR-FE 4.0L V6 in the FJ Cruiser shares lineage with the same V6 family that powered Tacomas, 4Runners, and Land Cruiser Prados. The FJ's older cousin engine, the 2UZ-FE V8 found in 100-series Land Cruisers and 4.7L Sequoias, is covered in our 2UZ-FE V8 deep dive. For the full model history of the Land Cruiser family, see The Epic History of the Toyota Land Cruiser.
Practical Tips Before You Buy
- Mount one tire first. Have the shop install one tire, cycle full lock both directions, and check UCA and body mount clearance before committing to the set.
- Buy Spidertrax, not eBay spacers. The 1.25″ hub-centric bolt-on spacers from Spidertrax are the FJ community standard. Off-brand slip-on spacers kill people.
- Mud flaps come off first. Five-minute fix. Solves most 275 and some 285 rubbing complaints.
- Heat gun the front fender liner. Before you cut anything, heat the plastic and push it back with a 2x4. Plastic remembers the new shape.
- The 1GR-FE handles 33s on stock 3.727 gears. You'll lose some highway MPG and hear more downshifting, but the motor is fine. Regear at 35s or if you hate the new shift cadence.
- FJ Cruisers have disc brakes all around. Bigger tires put more stress on the brakes. If you're going past 33s, upgraded brake pads (Hawk LTS, EBC Greenstuff) are cheap insurance.
- Alignment twice. Budget for one alignment right after the lift/tire install and a second one 500–1000 miles later after the suspension settles.
- Speedometer recalibration. 33s throw off the speedo by about 5–7%. Most 2007–2014 FJ ECUs can be reflashed by a dealer or aftermarket tuner (Ultra-Gauge, HP Tuners).
